Product Introduction
1.LP-8040 Low-Pressure Reverse Osmosis Membrane Elements Applications and Suitability
The LP-8040 low-pressure reverse osmosis membrane elements are ideally suited for the desalination of water with a maximum salt concentration of 2000 mg/L. These elements can utilize municipal tap water or groundwater as the source water. They are extensively employed in various sectors, including residential water supply systems, facilities for the production of pure water, and in industrial and food production processes.
2.LP-8040 Main Product Advantages
High permeability, high water production rate, low-pressure operation, low energy consumption, and reduced operating costs.
3.LP-8040 Main Parameters
|
Model |
Effective Membrane Area ft2 (m2) |
Daily Water Production GDP(m3/d) |
Stable Salt Rejection Rate(%) |
Operating Pressure (PSI) |
|
YIME-LP-8040 |
400(37.2) |
11000(41.6) |
99.5 |
150 |
|
YIME-LP-4040 |
85(7.9) |
2400(9.8) |
99.5 |
15 |
4.LP-8040 standard testing condition
|
Test Feed Water |
Test Temperature |
pH Value |
Recovery Rate(%) |
Operating Pressure(PSI) |
|
2000PPM(Nacl) |
25±5 |
7.5～8 |
15±5 |
5 |
5.LP-8040 Parameter Table
|
Maximum Operating Pressure |
1.5Mpa |
Membrane Element Length |
40″ |
|
Free Chlorine Tolerance |
＜0.1ppm |
Membrane Element Diameter |
8″ |
|
pH Range |
6～9/4～11 |
Central Tube Diameter |
1.125″ |
|
Maximum Feedwater Turbidity |
＜1NTU |
Weight |
12kg |
|
Maximum Feedwater SDI |
5.0 |
Spacer Thickness |
30mil |
|
Maximum Feedwater Flow Rate |
15m3/h |
Effective Membrane Area |
37m2 |
|
Maximum Operating Temperature Range |
0＜LP-8040＜45 |
Desalination Rate |
99.6%(3000ppm Nacl )25℃ |
|
Concentration Ratio (Production: Feed) |
5：1 |
Water Production |
28.4m3/d(3000ppm Nacl)25℃ |
|
Maximum Pressure Drop |
1kg/cm2 |
Boron Removal Rate |
89% |
Product Specifications
- Model: YIME-LP-8040
- Capacity: 41.6m3/d
- Desalination: 99%
- Place of Origin: Guangdong, China
- Delivery Time: 2-7 days
- Supply Ability: 3,000 pcs/day
Why Choose Our Product
- Manufacturing Expertise: Boasting a daily production capacity of 3,000 units, we excel in rapidly fulfilling substantial orders while upholding rigorous quality benchmarks. As a manufacturer, we serve both the B2B and B2C sectors, offering adaptability to distributors and end-users alike.
- OEM/ODM Services: We deliver tailored solutions, providing Original Equipment Manufacturer (OEM) and Original Design Manufacturer (ODM) services to cater to the distinct requirements of our clientele.
- Global Shipping & Support: We guarantee swift and secure delivery of our LP-8040 reverse osmosis membranes globally, utilizing express, sea, land, or air transport options.
- Sample Availability: We provide paid samples, enabling potential customers to evaluate our products prior to committing to bulk purchases, thus ensuring their complete confidence.
For further inquiries or pricing details, please contact us via:
Email: 263816674@qq.com
Wechat/Zalo/WhatsApp: +86-133-3263-1293
WhatsApp:+8613332682173
